ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH

ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH is a pressure vessel steel grade as specified under the Euro Norm standard (EN10028) which has superseded British standard and DIN standard equivalents. ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH is a normailized steel which is designed for use in elevated temperatures.

ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH chemical composition:

Grade

Mn.

Ti.

Si.

AL.

Cr.

Mo.

Ni.

max

P355GH

0.10-0.22

1.10-1.70

0.015

0.012

0.3

0.02

0.03

0.6

0.025

0.02

0.3

0.08

0.3

0.02

ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH mechanical properties:

Grade	Type	Thickness	Yield strength	Tensile Strength	Elongation	Impact Energy
		mm	Mpa(min)	MPa	% (min)	(KVJ) (min)
						-20°	0°	20
P355GH	Normalized	≤16	355	510-650	20	27	34	40
		16>to≤40	345	510-650	20	27	34	40
		40>to≤60	335	460-580	20	27	34	40
		60>to≤100	315	490-630	20	27	34	40
		100>to≤150	295	480-630	20	27	34	40
		150>to≤250	280	470-630	20	27	34	40

ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH shows good tensile and yield strength and has good welding characteristics when using conventional welding methods. ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH also offers good cold and hot forming properties. ASTM A516 Gr 70 equivalent EN standard pressure vessel steel P355GH is used worldwide by fabricators of welded pressure vessels, industrial boilers and heat exchangers and is engineered to work well in elevated temperature service.

The main pressure vessel steel grades of BBN steel are A202, A203, A204, A285, A299, A302, A387, A515, A516, A517, A533, A537, A612, A662, A841; P235GH P265GH P295GH P355GH 16Mo3; P275NH P275NL1 P275NL2 P355N P355NH P355NL1 P355NL2 P460NH P460NL1 P460NL2; P355M P355ML1 P355ML2 P420M P420ML1 P420ML2 P460M P460ML1 P460ML2; P355Q P355QH P355QL1 P355QL2 P460Q P460QH P460QL1 P460QL2 P500Q P500QH P500QL1 P500QL2 P690Q P690QH P690QL1 P690QL2; SPV235 SPV315 SPV355 SPV410 SPV450 SPV490; SB410 SB450 SB480 SB450M SB480M; Q245R Q345R Q370R 18MnMoNbR 15CrMoR 14Cr1MoR 13MnNiMoR 12Cr2Mo1R 12Cr1MoVR; 16MnDR 15MnNiDR 09MnNiDR; HI HII 17Mn4 19Mn6 15Mo3 13CrMo44 10CrMo9-10 and so on.
