DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate

DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate

DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate Chemical Composition and Mechanical Property

Grade C% SI% Mn% P%, max S%, max Al% Cr% Cu%, max Mo% Nb%, max Ni%, max Ti%, max V%, max
19Mn6 0.15-0.22 0.3-0.6 1.0-1.6 0.035 0.03 ≥0.020 ≤O.25 0.3 ≤O.10 0.01 0.3 0.03 0.03
Steel Grade Thickness, in mm Yield Strength, min Tensile Strength Elongation, %, min
19Mn6 T≤16 355 510-650 20
16<T≤40 345
40<T≤60 335
60<T≤100 315 490-630 20
100<T≤150 295 480-630



DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate Application

DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.

DIN 17155 19Mn6 Pressure Vessel And Boiler Steel Plate Other Name

DIN 17155 19Mn6 Boiler steel plate,DIN 17155 19Mn6 Pressure Vessel Steel plate, DIN 17155 19Mn6 Storage Tanks Steel plate. DIN 17155 19Mn6 Heat Exchanger Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
