ASTM A36 Steel plate equivalent grade Q235B in China

ASTM A36 Steel plate equivalent grade is Q235B in China. The two equivalent steel grades have much in common without any doubt. However, you will get to know that there are many difference between ASTM A36 steel plate and Q235B steel plate also if you check carefully the technical data comparison between Q235B and A36 as below :

ASTM A36 Steel plate equivalent grade Q235B and A36 steel contrast table (1):

Grade	Chemical composition %
Grade	C	Si	Mn	P	S	Cu
Q235B	0.2 max	0.35 max	1.40 max	0.045 max	0.045 max	-
A36	0.26 max	0.40 max	-	0.04 max	0.05 max	0.20 min

When steel plate thickness upper than 20mm, A36 steel plate Mn is 0.8%-1.20%, while ASTM A36 Steel plate equivalent grade Q235B is 0.30%-0.70%

ASTM A36 Steel plate equivalent grade Q235B and A36 steel contrast table (2) --- mechanical properties:

Grade	Yield strength ReH/(N/mm2) (t≤16mm) min	Tensile strength Rm/(N/mm2) (3mm≤t≤16mm)	Elongation A/% (3mm≤t≤40mm) min	Charpy V test
Grade	Yield strength ReH/(N/mm2) (t≤16mm) min	Tensile strength Rm/(N/mm2) (3mm≤t≤16mm)	Elongation A/% (3mm≤t≤40mm) min	Temperature/℃	Impact energy (Longitudinal)/J min
Q235B	235	370-500	26	20	27
A36	250	400-550	23	-	-

The minimum yield point of ASTM A36 Steel plate is 250 MPa, tensile strength is 400MPa-550MPa. While the minimum yield point of ASTM A36 Steel plate equivalent grade Q235B is 235MPa, tensile strength is 375MPa-460Mpa. That means some Q235B will not meet A36 requirements.

A36 steel is also equivalent to EN S235JR, DIN ST37-2, JIS SS400 etc.
