LR Grade DH40 Shipbuilding Steel Plate

LR Grade DH40 Shipbuilding Steel Plate

LR Grade DH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

C max Si max Mn P max S max Als Nb V Ti max. Cu max. Cr max. Ni max. Mo max. N max.

0.18

0.50 0.90-1.60

0.025

0.025

0.015 0.02-0.05 0.05-0.10 0.02 0.35 0.20 0.40 0.08

-

Yield Strength (MPa) min. Tensile Strength (MPa) Elongation min. %
390 510-660 20

LR Grade DH40 Shipbuilding Steel Plate Application

LR Grade DH40 Shipbuilding steel plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.

LR Grade DH40 Shipbuilding Steel Plate Other Name

LR Grade DH40 Shipbuilding steel plate, LR Grade DH40 Ship steel plate, LR Grade DH40 Marine steel plate, LR Grade DH40 steel plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
