JIS G3461 STB510 boiler steel pipe

JIS G3461 STB510 boiler steel pipe Chemical Composition and Mechanical Property

C	Si	Mn	P	S
≤0.25	≤0.35	1.00-1.50	≤0.035	≤0.035

Grade	Tensile Strength	Yield Point	Elongation %
STB510	N/mm2	N/mm2	OD<10mm	10≤OD<20	OD≥20
STB510	≥410	≥255	≥17	≥20	≥25

JIS G3461 STB510 boiler steel pipe Application

As a kind of low-medium boiler tube, STB510 boiler steel pipe is mainly used for producing low and medium boiler, super-heated steam tube, boiling-water tube, water wall tube, which is suitable for high working temperature.

JIS G3461 STB510 boiler steel pipe Other Name

JIS G3461 STB510 boiler steel pipe, STB510 boiler pipe, STB510 steel pipe

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
