DIN17175 10CrMo910 boiler steel pipe

DIN17175 10CrMo910 boiler steel pipe Chemical Composition and Mechanical Property

Grade	Material	C	Si	Mn	P	S	Cr	Mo
10CrMo910	1.7380	0.08-0.15	≤0.50	0.40-0.70	0.035	0.035	2.00-2.50	0.90-1.20

Grade	Material	Tensile strength N/mm2	Yield strength thickness,mm			Elongation (L=5do)		Notch impact energy
			≤16	>16≤40	>40≤60
			N/mm2 min
10CrMo910	1.7380	450-600	280	280	270	20	18	34

DIN17175 10CrMo910 boiler steel pipe Application

DIN17175 10CrMo910 boiler steel pipe applies to seamless tubes including tubes for headers of heat-resistant steels which are used in the construction of boilers,pipe-lines,pressure vessels and equipment

DIN17175 10CrMo910 boiler steel pipe Other Name

DIN17175 10CrMo910 boiler steel pipe, 10CrMo910 boiler steel , 10CrMo910 steel pipe

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
