DIN 17102 StE460 Automobile structure steel plate

DIN 17102 StE460 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade	C ≤	Si	Mn	P ≤	S ≤	N ≤	Al ≥	Cr ≤	Cu ≤	Mo ≤	Ni ≤	Nb ≤	Ti ≤	V ≤	Nb+Ti+V ≤
StE460	0.20	0.10~0.60	1.00~1.70	0.035	0.030	0.020	0.020	0.30	0.20	0.10	1.00	0.05	---	0.20	0.22

Grades

Tensile Strength R_m for
product thicknesses s,in mm
N/mm²

UpperYield StressR_eH²) for product thicknesses s,in mm
N/mm² min.

Elongation after fracture³)
(L_o=5d_o) % min.

Mandrel diameter for bend test 4), 5)

s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

s≤16

16＜s≤35

35＜s≤50

50＜s≤60

60＜s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

Longitudinal

Transverse 6)

StE460

560~730

550~720

540~710

530~700

520~690

460

450

440

430

420

410

400

390

380

DIN 17102 StE460 Automobile structure steel plate Application

StE460 steel plate is widely used in automotive, pressure vessels, chemical equipment, metal products, solar energy, structural pipe, architectural, mechanical manufacturing.

DIN 17102 StE460 Automobile structure steel plate Other Name

StE460 structure steel plate, DIN 17102 StE460 steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
