ASME SA514Grade C(SA514GRC) Carbon Steel Plate

ASME SA514Grade C(SA514GRC) Carbon Steel Plate Chemical Composition and Mechanical Property

Grade

A514GrC

0.10-0.20

1.10-1.50

≤0.035

≤0.04

0.15-0.30

0.20-0.30

0.001-0.005

Grade	Thickness Inch	Yield Strength Mpa	Tensile Strength Mpa	Elongation in 50mm	Hardnees Brinell
A514GrC	less 3/4 inch	690	760-895	18	235
	over 3/4 to 2 1/2	690	760-895	18	~
	over 2 1/2 to 6 inch	620	690-895	16	~

ASME SA514Grade C(SA514GRC) Carbon Steel Plate Application

ASME SA514Grade C(SA514GRC) Steel Plate are used in Construction of Bridges, Highway Construction and Other Engineering construction

ASME SA514Grade C(SA514GRC) Carbon Steel Plate Other Name

ASME SA514Grade C(SA514GRC) Carbon Structural Steel Plate,ASME SA514Grade C(SA514GRC) Steel Plate,ASME SA514Grade C(SA514GRC) Carbon Steel plate,ASME SA514Grade C(SA514GRC) Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
