EN10028-2 16Mo3 material properties

EN10028-2 16Mo3 material is a chrome molybdenum based steel with excellent heat resistance and corrosion resistant characteristics.

EN10028-2 16Mo3 material properties:
1) EN10028-2 16Mo3 material chemical properties

Grade	C.max	Mn.	S.	N	Cu	Si.	P.	Cr.	Ni.	Mo.
16Mo3	0.12-0.2	0.40-0.90	0.01	0.012	0.30	0.35	0.025	0.30	0.30	0.25-0.35

2) EN10028-2 16Mo3 material mechanical properties:

Grade	Tensile Strength(Mpa)	Yield Strength(Mpa)	Elongation in100-150 mm(%)	Elongation in16 mm(%)	Max Thickness(mm)
16Mo3	440-590	220-275	19	24	250

EN10028-2 16Mo3 material properties enable it to be used in power plant equipment, industrial exhaust, venting and flare systems and waste recycling and incineration plants. In power plants, 16Mo3 material is regularly used in boilers, superheater tubes, collector and hot steam pipes, stove tubes and conduits. EN10028-2 16Mo3 material is also used in various types of heat exchanger in both the upstream and downstream oil and gas industry.
