ASTM A516 steel plate

ASTM A516 steel plate is utilized primarily in welded pressure vessels for moderate to lower temperature service. ASTM A516 steel plate is produced in 4 grades: A516 Grade 55, A516 Grade 60, A516 Grade 65, A516 Grade 70.

ASTM A516 Steel Plate Properties:

Grade	A516 Grade 55	A516 Grade 60	A516 Grade 65	A516 Grade 70
Common PGI Inventory	0.375″-4.75″ inquire for thicker plate	0.375″-4.75″ inquire for thicker plate	0.375″-4.75″ inquire for thicker plate	0.375″-4.75″ inquire for thicker plate
Minimum Yield Stress (ksi)	30	32	35	38
Average Tensile Strength (ksi)	55 – 75	60 – 80	65 – 85	70 – 90
Elongation at Breakage (8 in.)	23%	21%	19%	17%
Elongation at Breakage (2 in.)	27%	25%	23%	21%
% Carbon (C)	0.180 – 0.260	0.210 – 0.270	0.240 – 0.290	0.270 – 0.310
% Manganese (Mn)	0.600 – 1.30	0.850 – 1.30	0.850 – 1.30	0.850 – 1.30
% Phosphorus (P)	0.035	0.035	0.035	0.035
% Silicon (Si)	0.130 – 0.450	0.130 – 0.450	0.130 – 0.450	0.130 – 0.450
% Sulfur (S)	0.035	0.035	0.035	0.035

ASTM A516 steel plate is also offered in the normalized condition where improved notch toughness is required. The ASTM A516 steel plate shall be killed and shall conform to fine austenitic grain size requirements. The ASTM A516 steel plate shall be killed and shall conform to fine austenitic grain size requirements. The maximum thickness of ASTM A516 steel plate is limited only by the capacity of its composition to meet the specified A516 steel mechanical property requirements.
