ASTM A516 Gr 70 VS A36, ASTM A516 steel and A36 steel actually belong to different steel types. ASTM A516 steel is pressure vessel and boiler steel. ASTM A36 steel is mild steel. For the chemical content of carbon, ASTM A516 steel and A36 steel are also called carbon steel. But their properties have obvious difference.
ASTM A516 Gr 70 VS A36 carbon steel plate in chemical composition:
ASTM A36 carbon steel plate chemical composition:
| Grade | C (t≤16mm) | Si | Mn | P | S |
| A36 | 0.26 max | 0.40 max | - | 0.040 max | 0.050 max |
ASTM A516 Gr 70 carbon steel plate chemical composition:
| Chemical elements | Percentage % | Chemical elements | Percentage % |
| C | 0.10/ 0.22 | Cu | 0.30 |
| Si | 0.6 | Ni | 0.30 |
| Mn | 1/ 1.7 | Mo | 0.08 |
| P | 0.03 | Nb | 0.01 |
| S | 0.03 | Ti | 0.03 |
| Al | 0.02 | V | 0.02 |
| Cr | 0.3 |
ASTM A516 Gr 70 VS A36 carbon steel plate in mechanical properties:
ASTM A36 carbon steel plate mechanical properties:
| Grade | Yield strength ReH/(N/mm2) | Tensile strength Rm/(N/mm2) (3mm≤t≤16mm) |
Elongation A/% |
| (t≤16mm) min | (3mm≤t≤40mm) min | ||
| A36 | 250 | 400-550 | 23 |
ASTM A516 Gr 70 carbon steel plate mechanical properties:
| Grade | Tensile strength (MPa) |
Minimum yield strength (MPa) |
Minimum elongation (%) gauge length | |
| 50mm | 200mm | |||
| A516 Gr 70 | 485 - 620 | 260 | 21 | 17 |
ASTM A516 Gr 70 VS A36 carbon steel plate in application:
ASTM A36 carbon steel plate is used in heavy machinery, industrial boilers, wagon tippers, feeders, stackers, crushers, loaders, cranes, shipping industry and supporting frames for equipment used in metallurgical and other heavy industries.
ASTM A516 Gr 70 steel plate is mainly used for pressure vessel and boiler, oil and gas as well as petrochemical industries.
The main ASTM carbon steel plates and pressure vessel steel plates standards BBN steel conduct are:
ASTM carbon steel plates: A36, A283, A572, A573 and so on.
ASTM pressure vessel steel plates: A202, A203, A204, A285, A299, A302, A387, A515, A516, A517, A533, A537, A612, A662, A841, etc.
Other than ASTM standards, BBN steel also supply ASME, EN, JIS, DIN, GB and so on standard steel materials, and provide sheet metal fabrication service to meet diversified steel shape and size requirements.
Just like you, 70% customers choose long-term cooperation with BBN steel not only for our good product and service quality, good reputation in the international market, but also for our experienced one-stop raw material supply and further steel processing!
