EN 10028-3 P460NL1 steel and P460NL2 steel comparison

EN 10028-3 P460NL1 steel and P460NL2 steel have much in common, including P460NL1 P460NL2 steel chemical composition and mechanical properties. Their main difference lay in impact energy. Below is detailed analysis for you.

1)EN 10028-3 P460NL1 steel and P460NL2 steel chemical composition

EN 10028-3 steel Grade	C	Si	Mn	P	S	Altotal a	N	Cr	Cu b	Mo	Nb	Ni	Ti	V	Nb+Ti+V
P460NL1 steel	0.2	0.6	1.10-1.70	0.025	0.015	0.020 min	0.025	0.3	0.7	0.1	0.05	0.8	0.03	0.2	0.22
P460NL2 steel	0.2	0.6	1.10-1.70	0.02	0.01	0.020 min	0.025	0.3	0.7	0.1	0.05	0.8	0.03	0.2	0.22

The Al content may fall short of this minimum if Nb, Ti, or V are additionally used for Nitrogen binding. If only Al is used for Nitrogen binding, the ratio Al/N shall be 2 or greater.

If Cu exceeds 0.30%, Ni shall be at least half of the Cu content.

We can find that EN 10028-3 P460NL1 steel and P460NL2 steel chemical composition are almost same. The very small difference is that P460NL2 steel control more strictly for Phosphorus and Sulfur.

2)EN 10028-3 P460NL1 steel and P460NL2 steel mechanical properties are same

Product	Yield Strength	Tensile Strength	Elongation
Thickness	Mpa	Mpa	A%
up to 16 mm	460 min	570 to 730	17 min
16 to 40 mm	445 min	570 to 720	17 min
over 40 to 60 mm	430 min	570 to 720	17 min
over 60 to 100 mm	400 min	540 to 710	17 min

3)EN 10028-3 P460NL1 steel and P460NL2 steel impact energy values for the normalised condition

a) transverse	-50oC	-40 OC	-20 OC	0 OC	+20 OC
P460NL1 steel	-	27 J min	35 J min	50 J min	60 J min
P460NL2 steel	27 J min	30 J min	40 J min	60 J min	70 J min

b) longitudinal	-50oC	-40oC	-20oC	0 OC	+20oC
P460NL1 steel	30 J min	40 J min	50 J min	70 J min	80 J min
P460NL2 steel	42 J min	45 J min	55 J min	75 J min	85 J min

Please note: the technical information above is for guidance only – for exact specifications please check with us by artificial service./

We can find that EN 10028-3 P460NL1 steel and P460NL2 steel impact energy have obvious difference. If you are hesitated between P460NL1 steel and P460NL2 steel, please read this artical carefully, or result us directly.
