ABS Grade AH40 Shipbuilding Steel Plate

ABS Grade AH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

C max	Si max	Mn	P max	S max	Als	Nb	V	Ti max.	Cu max.	Cr max.	Ni max.	Mo max.	N max.
0.18	0.50	0.90-1.60	0.030	0.030	0.015	0.02-0.05	0.05-0.10	0.02	0.35	0.20	0.40	0.08	-

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
390	510-660	20

ABS Grade AH40 Shipbuilding Steel Plate Application

ABS Grade AH40 Shipbuilding steel plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.

ABS Grade AH40 Shipbuilding Steel Plate Other Name

ABS Grade AH40 Shipbuilding steel plate,ABS Grade AH40 Ship Steel plate ,ABS Grade AH40 Marine Steel plate , ABS Grade AH40 Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
