JIS G 3116 SG325 steel coils/sheets/plates for gas cylinders

JIS G 3116 SG325 steel coils/sheets/plates chemical composition:

Grade	C max	Si max	Mn max	P max	S max
SG325	0.20	0.55	1.50	0.040	0.040

JIS G 3116 SG325 steel coils/sheets/plates mechanical properties:

Grade	Yield strength	Tensile strength	Elongation % min
	Mpa (min)	Mpa (min)
SG325	325	490	22

IS G 3116 SG325 steel coils/sheets/plates are are structural hot rolled steel in the form of coils/sheets/plates for general gas cylinder applications to fill high-pressure gas such as liquefied petroleum gas, acetylene, various fluorine gas, etc. BBN JIS G 3116 SG325 steel coils/sheets/plates are mainly used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components. The applicable thickness of hot rolled SG325 LPG steel starts from 1.5 mm to 20 mm.Welcome to contact BBN steel for JIS G 3116 SG325 steel coils/sheets/plates technical data sheet, SG325 LPG steel price, SG325 LPG steel purchase etc. information.

SG325 steel coils, SG325 steel sheets, SG325 steel plates, SG325 gas cylinder steel, SG325 vessel steel

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
