GL Grade E690 Shipbuilding Steel Plate

GL Grade E690 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

C max	Si max	Mn	P max	S max	N max.
0.20	0.55	1.70	0.025	0.025	0.020

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
690	770-940	14

GL Grade E690 Shipbuilding Steel Plate Application

GL Grade E690 Shipbuilding steel plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.

GL Grade E690 Shipbuilding Steel Plate Other Name

GL Grade E690 Shipbuilding steel plate,GL Grade E690 Ship Steel plate ,GL Grade E690 Marine Steel plate , GL Grade E690 Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
