EN10216-2 X10CrMoVNb9-1 steel pipe

EN10216-2 X10CrMoVNb9-1 steel pipe

EN10216-2 X10CrMoVNb9-1 steel pipe Chemical Composition and Mechanical Property

EN10216-2 X10CrMoVNb9-1 steel pipe is Chromium-Molybdenum-Vanadium-Niobium alloy steel.
EN10216-2 X10CrMoVNb9-1 steel pipe contains super high chromium at 8.50-9.50%. So it owns special property for resistance of atmospheric corrosion and oxidization.

Chemical composition of EN10216-2 X10CrMoVNb9-1 steel pipe:

C Si Mn P max Smax Cr Mo Ni AL Cu Nb V
0.09-0.13 0.1-0.5 0.3-0.6 0.02 0.01 8.50-9.5 0.9-1.10 0.1-0.4 ≤0.040 - 0.06-0.1 0.18-0.25

Mechanical Properties of EN10216-2 X10CrMoVNb9-1 steel pipe:

Yield strength Tensile Strength Elongation A min %
T≤16 16<T≤40 40<T≤60 60<T≤100 Rm I t
450 450 450 450 630-830 19 17

EN10216-2 X10CrMoVNb9-1 steel pipe Application

EN10216-2 X10CrMoVNb9-1 steel pipe can be used to manufacture reheaters, superheaters and other heating surface tubes of high pressure boilers with metal wall temperature less than 650 C, and headers and steam conduits of boilers with metal wall temperature less than or equal to 600 C.

EN10216-2 X10CrMoVNb9-1 steel pipe Other Name

X10CrMoVNb9-1 pipe, X10CrMoVNb9-1 seamless steel pipe, X10CrMoVNb9-1 alloy steel pipe, X10CrMoVNb9-1 high pressure steel pipe, X10CrMoVNb9-1 boiler tube

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
