EN10216-2 16Mo3 seamless steel tubes for pressure purpose

EN10216-2 16Mo3 seamless steel tubes for pressure purpose Chemical Composition and Mechanical Property

EN10216-2 16Mo3 seamless steel tubes chemical composition:

Grade	C% max	Si% max	Mn% max	P% max	S% max	Cr% max	Mo% max	Ni% max	Al.cał% min	Cu% max	Nb% max	Ti% max	V% max	Cr+ Cu+ Mo+ Ni% Max
16Mo3	0.12- 0.20	0.35	0.40- 0.70	0.025	0.02	0.3	0.25- 0.35	0.3	≥ 0.020	0.3	-	-	-	-

EN10216-2 16Mo3 seamless steel tubes mechanical property:

Grade	Yield Strength min				Tensile Strength			Minimum energy average absorbed KVJ at the temperature of 0°C
	T≤16	16<T≤40	40<t≤60	60<T≤100	Tensile Strength	Elongation A min%		I		T
	MPa	MPa	MPa	MPa	MPa	I	t	20	0	-10	20	0
16Mo3	280	270	260	-	450- 600	22	20	40	-	-	27	-

EN10216-2 16Mo3 seamless steel tubes for pressure purpose Application

EN10216-2 16Mo3 seamless steel tubes are are used for high temperature service applications in oil refinery piping, steam pipeline, and power plant projects, etc.

EN10216-2 16Mo3 seamless steel tubes for pressure purpose Other Name

EN 10216-2 16Mo3 Seamless Steel Pipe, EN 10216-2 16mo3 Steel Pipe, EN 10216-2 16Mo3 boiler tube, EN 10216-2 Grade 16Mo3 Alloy Steel Seamless Tubes, EN 10216-2 16Mo3 Seamless Steel Boiler Tubes, EN 10216 2 16Mo3 pressure steel pipe, EN 10216-2 Grade 16Mo3

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
