EN10216-2 13CrMo4-5 seamless steel tubes for pressure purposes

EN10216-2 13CrMo4-5 seamless steel tubes for pressure purposes Chemical Composition and Mechanical Property

EN10216-2 13CrMo4-5 seamless steel tubes chemical composition:

C	Si	Mn	P	S	Cr	Mo	N	Cu
0.08 - 0.18	max 0.35	0.4 - 1	max 0.025	max 0.01	0.7 - 1.15	0.4 - 0.6	max 0.012	max 0.3

EN10216-2 13CrMo4-5 seamless steel tubes mechanical property:

Grade	Tensile Strength(MPa)	Yield Strength(MPa)	Elongation in 2 in.(50mm)
13CrMo4-5	440-590	280	20% min

EN10216-2 13CrMo4-5 seamless steel tubes for pressure purposes Application

EN10216-2 13CrMo4-5 seamless steel tubes are used as boiler heating surface pipe, economizer, superheater, reheater, petrochemical industry pipe, etc.

EN10216-2 13CrMo4-5 seamless steel tubes for pressure purposes Other Name

13CrMo4-5 / 1.7335 Alloy special steel, EN 1.7335 (13CrMo4-5) Chromium Steel, EN 10216-2 13CrMo4-5 Alloy Steel Seamless Pipe, 13CrMo4-5 steel pipe,13CrMo4-5 seamless pipe, EN 10216-2 13CrMo4-5 Boiler Tube

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
