EN10025-4 S420M Carbon and Low-alloy High-strength Steel Plate

EN10025-4 S420M Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property

Grade		Chemical composition % MAX
Grade		C	Si	Mn	P	S	Nb	V	Al	Ti	Cr	Ni	Mo	N
S420M		0.18	0.55	1.8	0.035	0.03	0.06	0.14	0.015	0.06	0.35	0.85	0.23	0.027
		Mechanical properties MIN
		Yield strength (Mpa)						Tensile strength (Mpa)					Elongation %
	TH(MM)	≤16	>16≤40	>40≤63	>63 ≤80	>80≤100	>100≤150	≤40	>40≤63	>63 ≤80	>80≤100	>100≤120
		420	400	390	380	370	365	520-680	500-660	480-640	470-630	460-620	19

EN10025-4 S420M Carbon and Low-alloy High-strength Steel Plate Application

EN10025-4 S420M Steel Plate are used in Construction of Bridges, Highway Construction and Other Engineering construction

EN10025-4 S420M Carbon and Low-alloy High-strength Steel Plate Other Name

EN10025-4 S420M Carbon Structural Steel Plate,EN10025-4 S420M High Strength Structural Steel Plate,EN10025-4 S420M Carbon Steel plate,EN10025-4 S420M Structural Steel Plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
