DIN17175 15Mo3 boiler steel pipe

DIN17175 15Mo3 boiler steel pipe Chemical Composition and Mechanical Property

Grade	C	Si	Mn	P	S	Cr	Mo	Ni	V
15Mo3	0.12~0.20	0.10~0.35	0.40~0.80	≤0.035	≤0.035	-	0.25~0.35	-	-

Grade	N/mm2	Wall Thickness mm			L=5do		DVM
		≤16	>16≤40	>40≤60	Longitudinal	Horizontal	Horizontal
		N/mm2 min			% min		min
15Mo3	450~600	270	270	260	22	20	34

DIN17175 15Mo3 boiler steel pipe Application

DIN17175 15Mo3 boiler steel pipe is mainly used for steam boiler, pipe, pressure vessel and meter working in the high temperature.

DIN17175 15Mo3 boiler steel pipe Other Name

DIN17175 15Mo3 boiler steel pipe, DIN17175 15Mo3 pipe, 15Mo3 boiler pipe

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
