DIN 17155 HII Pressure Vessel And Boiler Steel Plate

DIN 17155 HII Pressure Vessel And Boiler Steel Plate Chemical Composition and Mechanical Property

Grade

SI%

Mn%

P%, max

S%, max

Al%

Cr%

Cu%, max

Mo%

Nb%, max

Ni%, max

Ti%, max

V%, max

HII

≤O.20

≤O.35

0.5-1.3

0.035

0.03

≥0.020

≤O.25

0.3

≤O.10

0.01

0.3

0.03

Steel Grade	Thickness, in mm	Yield Strength, min	Tensile Strength	Elongation, %, min
HII	T≤16	265	410-530	22
	16<T≤40	255
	40<T≤60	245
	60<T≤100	215	410-530	21
	100<T≤150	200	400-530	21

DIN 17155 HII Pressure Vessel And Boiler Steel Plate Application

DIN 17155 HII Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.

DIN 17155 HII Pressure Vessel And Boiler Steel Plate Other Name

DIN 17155 HII Boiler steel plate,DIN 17155 HII Pressure Vessel Steel plate, DIN 17155 HII Storage Tanks Steel plate. DIN 17155 HII Heat Exchanger Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
