DIN 17102 WStE315 Automobile structure steel plate

DIN 17102 WStE315 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade	C ≤	Si	Mn	P ≤	S ≤	N ≤	Al ≥	Cr ≤	Cu ≤	Mo ≤	Ni ≤	Nb ≤	Ti ≤	V ≤	Nb+Ti+V ≤
WStE315	0.18	≤0.45	0.70~1.50	0.035	0.030	0.020	0.020	0.30	0.20	0.08	0.30	0.03	---	---	0.05

Grades

Tensile Strength R_m for
product thicknesses s,in mm
N/mm²

UpperYield StressR_eH²) for product thicknesses s,in mm
N/mm² min.

Elongation after fracture³)
(L_o=5d_o) % min.

Mandrel diameter for bend test 4), 5)

s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

s≤16

16＜s≤35

35＜s≤50

50＜s≤60

60＜s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

Longitudinal

Transverse 6)

WStE315

440~560

430~550

420~540

410~530

400~520

315

305

295

285

275

265

255

2.5a

DIN 17102 WStE315 Automobile structure steel plate Application

DIN 17102 WStE315 steel plate can be used in automotive industry, bicycle parts, general machinery, manufacturing housing, bracket, etc.

DIN 17102 WStE315 Automobile structure steel plate Other Name

DIN 17102 WStE315 steel plate, WStE315 Automobile structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
