DIN 17102 WStE285 Automobile structure steel plate

DIN 17102 WStE285 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade	C ≤	Si	Mn	P ≤	S ≤	N ≤	Al ≥	Cr ≤	Cu ≤	Mo ≤	Ni ≤	Nb ≤	Ti ≤	V ≤	Nb+Ti+V ≤
WStE285	0.18	≤0.40	0.60~1.40	0.035	0.030	0.020	0.020	0.30	0.20	0.08	0.30	0.03	---	---	0.05

Grades

Tensile Strength R_m for
product thicknesses s,in mm
N/mm²

UpperYield StressR_eH²) for product thicknesses s,in mm
N/mm² min.

Elongation after fracture³)
(L_o=5d_o) % min.

Mandrel diameter for bend test 4), 5)

s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

s≤16

16＜s≤35

35＜s≤50

50＜s≤60

60＜s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

Longitudinal

Transverse 6)

WStE285

390~510

380~500

370~490

360~480

350~470

285

275

265

255

245

235

225

1.5a

DIN 17102 WStE285 Automobile structure steel plate Application

WStE285 structure steel plate is widely used in automobiles, springs, agricultural machinery, motorcycles, chemicals, tools, construction machinery, chains and other manufacturing industries.

DIN 17102 WStE285 Automobile structure steel plate Other Name

DIN 17102 WStE285 steel plate, WStE285 Automobile structure steel plate, WStE285 structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
