DIN 17102 TStE500 Automobile structure steel plate

DIN 17102 TStE500 Automobile structure steel plate

DIN 17102 TStE500 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade C
Si Mn P
S
N
Al
Cr
Cu
Mo
Ni
Nb
Ti
V
Nb+Ti+V
TStE500 0.21 0.10~0.60 1.00~1.70 0.030 0.025 0.020 0.020 0.30 0.20 0.10 1.00 0.05 --- 0.22 0.22
Grades Tensile Strength Rm for
product thicknesses s,in mm
N/mm²
UpperYield StressReH²) for product thicknesses s,in mm
N/mm² min.
Elongation after fracture3)
(Lo=5do) % min.
Mandrel diameter for bend test 4), 5)
s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 s≤16 16<s≤35 35<s≤50 50<s≤60 60<s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 Longitudinal Transverse 6)
TStE500 610~780 600~770 590~760 580~750 570~740 500 480 470 460 450 440 430 420 410 16 3a 4a

DIN 17102 TStE500 Automobile structure steel plate Application

DIN 17102 TStE500 steel plate is mainly used in automotive industry,construction, manufacturing housing,and other industries.

DIN 17102 TStE500 Automobile structure steel plate Other Name

DIN 17102 TStE500 structure steel plate,TStE500 Automobile structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
