Home > steel plate > Automobile structure steel plate > DIN 17102

DIN 17102 TStE355 Automobile structure steel plate

DIN 17102 TStE355 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade	C ≤	Si	Mn	P ≤	S ≤	N ≤	Al ≥	Cr ≤	Cu ≤	Mo ≤	Ni ≤	Nb ≤	Ti ≤	V ≤	Nb+Ti+V ≤
TStE355	0.18	0.10~0.50	0.90~1.65	0.030	0.025	0.020	0.020	0.30	0.20	0.08	0.30	0.05	---	0.10	0.12

Grades

Tensile Strength R_m for
product thicknesses s,in mm
N/mm²

UpperYield StressR_eH²) for product thicknesses s,in mm
N/mm² min.

Elongation after fracture³)
(L_o=5d_o) % min.

Mandrel diameter for bend test 4), 5)

s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

s≤16

16＜s≤35

35＜s≤50

50＜s≤60

60＜s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

Longitudinal

Transverse 6)

TStE355

490~630

480~620

470~610

460~600

450~590

355

345

335

325

315

305

295

DIN 17102 TStE355 Automobile structure steel plate Application

TStE355 structure steel plate is mainly used in automotive industry, bicycle parts, general machinery, manufacturing housing, and other stamping parts.

DIN 17102 TStE355 Automobile structure steel plate Other Name

TStE355 Automobile structure steel plate, DIN 17102 TStE355 structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
