DIN17102 TStE285 Carbon and Low-alloy High-strength Steel Plate

DIN17102 TStE285 Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property

S% max	N% max	Al % max	Cr % max	Cu % max	Mo % max	Ni %	Nb % max
0.025	0.2	0.2	0.3	0.20	0.08	0.3	0.03

Tensile strength Mpa min					Yield Strength Mpa Min
390-510	380-500	370-490	360-480	350-480	285	285	276	265	265	255	245	235	225	24

DIN17102 TStE285 Carbon and Low-alloy High-strength Steel Plate Application

DIN17102 TStE285 Steel Plates are used in Construction of Bridges, Highway Construction and Other Engineering construction

DIN17102 TStE285 Carbon and Low-alloy High-strength Steel Plate Other Name

DIN17102 TStE285 Carbon Structural Steel Plate, DIN17102 TStE285 High Strength Structural Steel Plate, DIN17102 TStE285 Carbon Steel plate, DIN17102 TStE285 Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
