DIN17102 WStE255 Carbon and Low-alloy High-strength Steel Plate

DIN17102 WStE255 Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property

S% max	N% max	Al % max	Cr % max	Cu % max	Mo % max	Ni %	Nb % max
0.03	0.2	0.2	0.3	0.20	0.08	0.3	0.03

Tensile strength Mpa min					Yield Strength Mpa Min
t≤70	70＜t ≤ 85	85 ＜t ≤ 100	100 ＜t ≤ 125	125 ＜t ≤ 150	t≤16	16＜t ≤ 35	35 ＜t ≤ 60	50 ＜t ≤ 60	60 ＜t ≤ 70	70＜t ≤ 85	85 ＜t ≤ 100	100 ＜t ≤ 125	125 ＜t ≤ 150	Elongation % min
360-480	350-470	340-460	330-450	330-450	255	255	245	235	235	225	215	205	195	25

DIN17102 WStE255 Carbon and Low-alloy High-strength Steel Plate Application

DIN17102 WStE255 Steel Plates are used in Construction of Bridges, Highway Construction and Other Engineering construction

DIN17102 WStE255 Carbon and Low-alloy High-strength Steel Plate Other Name

DIN17102 WStE255 Carbon Structural Steel Plate, DIN17102 WStE255 High Strength Structural Steel Plate, DIN17102 WStE255 Carbon Steel plate, DIN17102 WStE255 Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
