Austenitic 305(S30500) stainless steel plate/coil

Austenitic 305(S30500) stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other Elements
305(S30500)	0.12	2.00	0.045	0.030	0.75	17.0 - 19.0	10.5 - 13.0	---	---	---	---

Grade	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50 mm, min, %	Hardness, maxC		Cold Bend°D
Grade	ksi	MPa	ksi	MPa	Elongation in 2 in. or 50 mm, min, %	Brinell	Rockwell B	Cold Bend°D
305(S30500)	70	485	25	170	40	183	88	not required

Austenitic 305(S30500) stainless steel plate/coil Application

A240 305 stainless steel plate/coil is widely used in Spun or deep drawn eyelets, Barrels, Shells, Cold headed rivets or screws.

Austenitic 305(S30500) stainless steel plate/coil Other Name

A240 305 stainless steel plate/coil, UNS S30500 stainless steel plate/coil, Austenitic 305(S30500) stainless steel plate/coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
