Austenitic 301L(S30103) stainless steel plate/coil

Austenitic 301L(S30103) stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other Elements
301L(S30103)	0.03	2.00	0.045	0.030	1.00	16.0 - 18.0	6.0 - 8.0	---	0.20	---	---

Grade	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50 mm, min, %	Hardness, maxC		Cold Bend°D
Grade	ksi	MPa	ksi	MPa	Elongation in 2 in. or 50 mm, min, %	Brinell	Rockwell B	Cold Bend°D
301L(S30103)	80	550	32	220	45	241	100	not required

Austenitic 301L(S30103) stainless steel plate/coil Application

301L(S30103) stainless steel plate/coil is widely used in railway vehicle architecture and an exterior material.

Austenitic 301L(S30103) stainless steel plate/coil Other Name

ASTM_A240 301L stainless steel plate/coil, 301L(S30103) stainless steel plate/coil, UNS S30103 stainless steel plate/coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
