ASTM A514/A514M Grade T Carbon and Low-alloy High-strength Steel Coil
ASTM A514/A514M Grade T Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
|
Grade |
The Element Max (%) |
|||||
|
A514 Grade T |
C |
Mn |
P |
S |
Si |
Ni |
|
0.08-0.14 |
1.20-1.50 |
0.035 |
0.010 |
0.40-0.60 |
- |
|
|
Cr |
Mo |
V |
Cu |
B |
Co |
|
|
- |
0.45-0.60 |
0.03-0.08 |
- |
0.001-0.005 |
- |
|
|
A514 Grade T |
Thickness |
Yield |
Tensile |
Elongation |
|
mm |
Min Mpa |
Mpa |
Min % |
|
|
6-20 |
690 |
760-895 |
18 |
|
|
20-65 |
690 |
760-895 |
18 |
|
|
65-150 |
620 |
690-895 |
16 |
ASTM A514/A514M Grade T Carbon and Low-alloy High-strength Steel Coil Application
A514/A514M Grade T carbon steel coil is used in Construction of Bridges, Highway Construction and Other Engineering construction.
ASTM A514/A514M Grade T Carbon and Low-alloy High-strength Steel Coil Other Name
ASTM A514/A514M Low-alloy High-strength Steel, A514/A514M Grade T carbon steel coil, A514/A514M Grade T Low-alloy High-strength Steel Coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
