RINA D shipbuilding steel description:
RINA D shipbuilding steel is a common tensile strength steel. D shipbuilding steel is the Hull structural steel which with a good toughness properties, higher strength,strong corrosion-resistance, the processing properties,and welding properties.
RINA D shipbuilding steel Application range
RINA A shipbuilding steel can be used in the manufacture of the ship's hull structure whose weight is below 10000 tons, and usually do navigation around coastal and river area. Also, RINA D shipbuilding steel is widely used in oil platform and offshore platform.
RINA D shipbuilding steel supply size
Thickness: 4mm-260mm
Width: 1200mm-4000mm
Length: 3000mm-18000mm
(other plate sizes and thicknesses are available on request )
RINA D shipbuilding steel composition (%)
|
|
C max |
Si max |
Mn |
P max |
S max |
Als min |
|
D |
0.21 |
0.35 |
0.60-1.20 |
0.035 |
0.035 |
0.015 |
Note: CE: C+1/6Mn ≤ 0.40% Cu ≤ 0.35%,Ni ≤ 0.30%
RINA D shipbuilding steel mechanical property
|
|
Rm |
Re(MPa) min |
A% min |
Akv/J min |
||||||
|
D |
400-520 |
235 |
22 |
E.T °C |
Thickness (mm) |
|||||
|
-20 |
≤ 50 |
>50-70 |
>70-100 |
|||||||
|
L |
C |
L |
C |
L |
C |
|||||
|
27 |
20 |
34 |
24 |
41 |
27 |
|||||
Note: In the list , Rm: tensile strength, Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.
RINA D shipbuilding steel deliver condition:
|
|
category |
The thickness of steel |
||||
|
≤ 12 |
>12.5-25 |
>25-35 |
>35-50 |
>50-100 |
||
|
D |
Plate/sheet |
A(50) |
N(50) |
N(50) |
||
|
Profile steel |
N(50) |
- |
||||
Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society .
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.
Henan BEBON international co.,ltd is an outstanding and professional RINA D shipbuilding steel exporter and stockist in china. Based on our huge productive ability, RINA D shipbuilding steel stock is available, so if you have any need of RINA AH36 shipbuilding steel, we also can meet your maximum request. Welcome to call or email us for you need.
