LR FH40 shipbuilding steel description

LR FH40 steel plate for shipbuilding&platform. The shipbuilding steel plate grade FH40 is the high tensile strength steel. FH40 shipbuilding steel is the Hull structural steel,with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,welding properties and so on.

LR FH40 shipbuilding steel application range

With the super features of good toughness properties, higher strength,strong corrosion-resistance,the processing, FH40 steel plate/sheet widely used in the manufacture of the ship's hull structure, and usually do navigation around coastal and river area. Also, LR FH40 shipbuilding steel is widely used in oil platform and offshore platform.

LR FH40 shipbuilding steel supply size
Thickness: 4mm-260mm
Width: 1200mm-4000mm
Length: 3000mm-18000mm
(other plate sizes and thicknesses are available on request )

LR FH40 shipbuilding steel composition (%)

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V	N max
FH40	0.16	0.50	0.90-1.60	0.025	0.025	0.015	0.02	0.35	0.20	0.80	0.08	0.02-0.05	0.05-0.10	0.009

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm), ≤0.38%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

LR FH40 shipbuilding steel mechanical property

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
FH40	510-660	390	20	E.T °C	Thickness (mm)
				-40	≤ 50		>50-70		>70-100
					L	C	L	C	L	C
					41	27	-

Note: In the list, Rm: tensile strength, Re: Yield strength, A%: elongation, E.T: experimental temperature, L: lengthways, C: crosswise.

LR FH40 shipbuilding steel deliver condition

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
FH40	Any	Plate/sheet	N,TM,Q&T					-
		Profile steel	N(25),TM(25),Q&T(25)

Note: 1. delivery condition: A =Any; N=Normalized; CR=Control Rolled; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society.
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.

With the advanced productive technology and certification from the biggest eight Classification Society, Henan BEBON has became an outstanding exporter in steel plate, especial in LR FH40 shipbuilding steel. More information about LR FH40 shipbuilding steel plate, pls free to consult our sales-team.
