LR FH36 shipbuilding steel plate; LR FH36 shipbuilding sheet; LR FH36 shipbuilding plate supplier; LR FH36 shipbuilding plate price; LR FH36 hull structure steel; LR FH36 shipbuilding plate property.
LR FH36 shipbuilding steel description
LR FH36 steel plate, FH36 steel is a kind of steel for shipbuilding and platform. Shipbuilding steel plate FH36 is the high tensile strength steel with good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.
LR FH36 shipbuilding steel application range
With the super features of good toughness properties, higher strength,strong corrosion-resistance,the processing, FH36 steel plate/sheet widely used in the manufacture of the ship's hull structure, and usually do navigation around coastal and river area. Also, LR FH36 shipbuilding steel is widely used in oil platform and offshore platform.
LR FH36 shipbuilding steel supply size
Thickness: 4mm-260mm
Width: 1200mm-4000mm
Length: 3000mm-18000mm
(other plate sizes and thicknesses are available on request )
LR FH36 shipbuilding steel composition (%)
|
C max |
Si max |
Mn |
P max |
S max |
Als min |
Ti max |
Cu max |
Cr |
Ni |
Mo |
Nb |
V |
N max |
FH36 |
0.16 |
0.50 |
0.90-1.60 |
0.025 |
0.025 |
0.015 |
0.02 |
0.35 |
0.20 |
0.80 |
0.08 |
0.02-0.05 |
0.05-0.10 |
0.009 |
Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.36% (thickness ≤ 50mm), ≤0.38%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
LR FH36 shipbuilding steel mechanical property
|
Rm |
Re(MPa) min |
A% min |
Akv/J min |
||||||
FH36 |
490-630 |
355 |
21 |
E.T °C |
Thickness (mm) |
|||||
-60 |
≤ 50 |
>50-70 |
>70-100 |
|||||||
L |
C |
L |
C |
L |
C |
|||||
34 |
24 |
- |
- |
- |
- |
Note: In the list, Rm: tensile strength,Re: Yield strength, A%: elongation, E.T: experimental temperature, L: lengthways, C: crosswise.
LR FH36 shipbuilding steel deliver condition
|
Fine grains elements |
category |
The thickness of steel |
||||||
≤ 12 |
>12.5-20 |
>20-25 |
>25-35 |
>35-50 |
>50-100 |
||||
FH36 |
Any |
Plate/sheet |
N,TM,Q&T |
||||||
Profile steel |
N(25), TM(25), Q&T(15), CR*(25) |
- |
Note: 1. delivery condition: A =Any; N=Normalized; CR=Control Rolled; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society.
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.
We, Henan BEBON international is professional in exporting the steel for shipbuilding and oil platform, all kinds of shipbuilding steel plate are available with the certificate from the Classification Society. If you have any need of LR FH36 shipbuilding steel, pls feel free to contact our sales-team, we will supply you LR FH36 steel plate with the best quality, first class service, and competitive price.
