DIN 17102 TStE285 Automobile structure steel plate

DIN 17102 TStE285 Automobile structure steel plate

DIN 17102 TStE285 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade C
Si Mn P
S
N
Al
Cr
Cu
Mo
Ni
Nb
Ti
V
Nb+Ti+V
TStE285 0.16 ≤0.40 0.60~1.40 0.030 0.025 0.020 0.020 0.30 0.20 0.08 0.30 0.03 --- --- 0.05
Grades Tensile Strength Rm for
product thicknesses s,in mm
N/mm²
UpperYield StressReH²) for product thicknesses s,in mm
N/mm² min.
Elongation after fracture3)
(Lo=5do) % min.
Mandrel diameter for bend test 4), 5)
s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 s≤16 16<s≤35 35<s≤50 50<s≤60 60<s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 Longitudinal Transverse 6)
TStE285 390~510 380~500 370~490 360~480 350~470 285 275 265 255 245 235 225 24 1.5a 2a

DIN 17102 TStE285 Automobile structure steel plate Application

TStE285 structure steel plate is widely used in automotive, bridge engineering, engineering machinery, housing, chemical drums and other manufacturing industries.

DIN 17102 TStE285 Automobile structure steel plate Other Name

DIN 17102 TStE285 structure steel plate, TStE285 Automobile structure steel plate, DIN 17102 TStE285 steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
