ASME SA514Grade B(SA514GRB) Carbon Steel Plate

ASME SA514Grade B(SA514GRB) Carbon Steel Plate

ASME SA514Grade B(SA514GRB) Carbon Steel Plate Chemical Composition and Mechanical Property

Grade  C Mn P S SI Ni Cr Mo V Ti Zr Cu
A514GrB 0.12-0.21 0.7-1.0 ≤0.035 ≤0.04 0.2-0.35 ~ 0.4-0.65 0.15-0.25 0.03-0.08 0.01-0.03 ~ ~ 0.0005-0.005
Grade  Thickness
Inch
Yield Strength
Mpa
Tensile
Strength
Mpa
Elongation in 50mm Hardnees
Brinell
A514GrB less 3/4 inch 690 760-895 18 235
over 3/4 to 2 1/2  690 760-895 18 ~
over 2 1/2 to 6 inch 620 690-895 16 ~



ASME SA514Grade B(SA514GRB) Carbon Steel Plate Application

ASME SA514Grade B(SA514GRB) Steel Plate are used in Construction of Bridges, Highway Construction and Other Engineering construction

ASME SA514Grade B(SA514GRB) Carbon Steel Plate Other Name

ASME SA514Grade B(SA514GRB) Carbon Structural Steel Plate,ASME SA514Grade B(SA514GRB) Steel Plate,ASME SA514Grade B(SA514GRB) Carbon Steel plate,ASME SA514Grade B(SA514GRB) Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
