10CrMo9-10 10CrMo910 10CD9.10 622Gr.31

Share Click here to Get a price , or Send us an email

10CrMo9-10 10CrMo910 10CD9.10 622Gr.31]

The  EN 10028-2 10CrMo9-10 steel plate/sheet,Application of Pressure vessel &Boiler 10CrMo9-10 steel plate/sheet: widely used in petroleum, chemical, power station boilers making and other industries for the production of reactor, heat exchanger, separator, spherical tanks, oil cans, gas cans, nuclear reactor pressure vessel, boiler steam package, liquefied petroleum gas cylinders, high pressure water main station, hydraulic turbine vortex shells and other equipments and components;High-strength & low-alloy 10CrMo9-10  steel plate: widely used in plants building, general mansions and all kinds of construction machinery, such as mines and various types of drilling rig used in construction, power shovel, electric wheel dump trucks, mining vehicles, excavators, loaders, bulldozers , various types of cranes, hydraulic support, coal mining machinery and equipments and other structures.




10CrMo9-10 EN 10028-2 Number:1.7380		 Comparision of steel grades
DIN 17155 10 CrMo 9 10
NFA 36-205 10 CD 9.10
UNI 5869 -
BS 1501 622 Gr.31
UNE 36087 -
ASTM A 387 Gr.22
JIS G3115 -

10CrMo9-10 steel plate Chemical Composition [%]

Grade C.   Mn.   S.   N Cu Nb Ti.   Si. P.   AL. Cr. Mo. Ni. V.
10CrMo910 0.08-0.14 0.40-0.80 0.010 0.012 0.30 - - 0.50 0.020 - 2.00-2.50 0.90-1.10 - -

10CrMo9-10 steel sheet Mechnical Properties

Grade Thickness mm Yield strength Mpa Tensile Strength  MPa Elongation (A) % Impact Energy KV at Test temperature [J]
-20° 0° +20
    13CrMo 4-5 ≤16 310 480-630 18 - - 31
16>to≤40 300 480-630 18     31
40>to≤60 290 480-630 18 - - 31
60>to≤100 280 470-620 17 - - 27
100>to≤150 265 460-610 17 - - 27
150>to≤250 250 450-600 17 - - 27



Source:

Tags: 10CrMo9-10, 10CrMo910, 10CD9.10
