E 360 steel is for general Construction steel. E360 steel is according to EN10025 standard and it is equivalent to EN:FE690-2,DIN17100:St70-2,NFA: A70-2 and UNI7070:FE690 steel grades.
E 360 steel
E 360 steel Mechanical properties:
Tensile Strength sb(MPa) :
690-900(thickness under 3mm); 670-830(thickness above 3mm)
Yield Strength s0.2 :
>=360(thickness under 16mm); >=355(thickness above 16mm)
Elongation d5(%) :
>=4(thickness under 1.5mm);
>=5(thickness between 1.51-2mm);
>=6(thickness between 2.01-2.5mm);
>= 7(thickness between 2.51-2.99mm);
>=10(thickness above 3mm)
E 360 steel Heat Treatment:
Hardening: 800-840oC/oil, water
Tempering: See the diagram
Note: Diagram: Sample size: dia 60 mm
E 360 steel offered by BEBON has good quality to meet consumer's need. If need E 360 steel, we can reproduce the goods according to your requirements. If you are interested in E 360 steel, please contact us.
