SEW092 QStE340TM Automobile structure steel plate
SEW092 QStE340TM Automobile structure steel plate Chemical Composition and Mechanical Property
| Grade | C % | Si % | Mn % max. | P % | S % | Al % min. | Nb % max | Ti % max |
| QStE340TM | 0.12 | 0.50 | 1.30 | 0.03 | 0.03 | 0.015 | 0.09 | 0.22 |
| Grade | Yield Strength N/mm² mind. |
Tensile Strength N/mm² |
Elongation % | Technology bending test Mandrel diameter Da = Sample thickness bending angle180° |
|||
| Thickness＜3mm | ≥3mm≤6mm | ≥3mm | |||||
| L0= 80mm | L0= 50mm | L0= 50mm | L0= 5d0 | ||||
| QStE340TM | 340 | 420bis540 | 19 | 21 | 23 | 25 | D=0.5a |
SEW092 QStE340TM Automobile structure steel plate Application
QStE340TM steel plate can be used for produce automobile frames, beams and other automotive structural parts, with good cold formability and high strength.
SEW092 QStE340TM Automobile structure steel plate Other Name
QStE340TM Automobile structure steel plate, SEW092 QStE340TM steel plate
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
