JIS G3125-2004 SPA-H Weather Resistant Steel Coil
JIS G3125-2004 SPA-H Weather Resistant Steel Coil Chemical Composition and Mechanical Property
|
Grade |
The Element Max (%) |
|||||||
|
C max. |
Si |
Mn max. |
P |
S max. |
Cu |
Cr | Ni max. | |
|
SPA-H |
0.12 |
0.20-0.75 |
0.6 |
0.070-0.150 |
0.035 |
0.25-0.55 |
0.30-1.25 | 0.65 |
|
Grade |
|
|||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
SPA-H |
mm |
Min Mpa |
Min. Mpa |
Min % |
|
t≦6.0 |
355 |
490 |
22 |
|
|
T>6.0 |
355 |
490 |
15 |
|
JIS G3125-2004 SPA-H Weather Resistant Steel Coil Application
JIS G3125-2004 SPA-H weather resistant steel coil is used for Vehicle, Bridge, Tower and Containers.
JIS G3125-2004 SPA-H Weather Resistant Steel Coil Other Name
SPA-H weather resistant steel coil, JIS G3125-2004 SPA-H weather resistant steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
