GB/T4171 Q295NH Weather Resistant Steel Coil
GB/T4171 Q295NH Weather Resistant Steel Coil Chemical Composition and Mechanical Property
|
Grade |
Chemical Composition(%) |
||||
|
C Max |
Si |
Mn |
P |
S Max |
|
|
GB/T 4171 Q295NH |
0.15 |
0.10-0.50 |
0.03-1.00 |
0.030 |
0.030 |
| Yield Strength (MPa) min. (t≤16mm) | Yield Strength (MPa) min.(16mm<t≤25.4mm) | Tensile Strength (MPa) | Elongation % min.(t≤16mm) | Elongation % min.(16mm<t≤25.4mm) |
| 295 | 285 | 430-560 | 24 | 24 |
GB/T4171 Q295NH Weather Resistant Steel Coil Application
GB/T4171 Q295NH weather resistant steel coil is used for Vehicle, Bridge, Tower and Containers.
GB/T4171 Q295NH Weather Resistant Steel Coil Other Name
Q295NH weather resistant steel coil, GB/T4171 Q295NH weather resistant steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
