EN10155-1993 S355J0W Weather Resistant Steel Coil
EN10155-1993 S355J0W Weather Resistant Steel Coil Chemical Composition and Mechanical Property
|
C max |
Si max |
Mn | P |
S max |
N max |
Addition of Nitrogen combining elements | Cr | Cu |
|
0.16 |
0.50 |
0.50-1.50 | 0.040 |
0.040 |
0.009 |
- | 0.40-0.80 | 0.25-0.55 |
|
Yield Strength (MPa) min. |
Tensile Strength (MPa) |
Elongation % min. |
|||||
|
Thickness(mm) |
Thickness(mm) |
Thickness(mm) |
|||||
|
t≤16 |
16<t≤25.4 |
t<3 |
3≤t≤25.4 |
1.5<t≤2.0 |
2.0<t≤2.5 |
2.5<t<t3.0 |
3≤t≤25.4 |
|
355 |
345 |
510-680 |
490-630 | 16 | 17 | 18 | 22 |
EN10155-1993 S355J0W Weather Resistant Steel Coil Application
EN10155-1993 S355J0W weather resistant steel coil has wide applications such as Vehicle, Bridge, Tower and Containers.
EN10155-1993 S355J0W Weather Resistant Steel Coil Other Name
EN10155-1993 S355J0W weather resistant steel, EN10155-1993 S355J0W weather resistant steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
