DNV A500 Shipbuilding Steel Coil
DNV A500 Shipbuilding Steel Coil Chemical Composition and Mechanical Property
|
Grade |
Chemical Composition(%) |
|||||
|
C |
Mn |
Si |
P |
S |
||
|
DNV A500 |
0.21 |
1.70 |
0.10-0.55 |
0.035 |
0.035 |
|
|
Grade |
Mechanical Property |
|
||||
|
Tensile Strength(MPa) |
Yield Strength(MPa) |
% Elongation in 2 in.(50mm) min |
Impacting Test Temperature(°C) |
|
||
|
DNV A500 |
610-770 |
500 |
18 |
0 |
|
|
DNV A500 Shipbuilding Steel Coil Application
DNV A500 shipbuilding steel coil is used in Shipbuilding Project and Offshore Structural Project.
DNV A500 Shipbuilding Steel Coil Other Name
DNV A500 shipbuilding steel, DNV A500 shipbuilding steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
