ASME SA514/SA514M Grade E Carbon and Low-alloy High-strength Steel Coil
ASME SA514/SA514M Grade E Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
| Grade | The Element Max (%) | ||||||
| C | Si | Mn | P | S | Cr | Mo | |
| SA514Gr.E | 0.12-0.20 | 0.20-0.40 | 0.40-0.70 | 0.035 | 0.035 | 1.40-2.00- | 0.40-0.60 |
| Zr | B | V | Ti | Cu | |||
| - | 0.01-0.05 | - | 0.01-0.10 | 0.15-0.50 | |||
| Grade | Thickness | Yield Strength |
Tensile Strength | Elongation | Charpy V Notch Impact Test | |
| Degree | Min Value | |||||
| SA514Gr.E | mm | Min Mpa | Mpa | Min % | - | J |
| 5≤t≤20 | 690 | 760-895 | 18 | - | ||
| 20≤t≤65 | 690 | 760-895 | 18 | |||
| 65≤t≤150 | 620 | 690-895 | 18 | |||
ASME SA514/SA514M Grade E Carbon and Low-alloy High-strength Steel Coil Application
SA514 Grade E carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.
ASME SA514/SA514M Grade E Carbon and Low-alloy High-strength Steel Coil Other Name
ASME SA514/SA514M low-alloy high-strength steel, SA514 Grade E carbon steel coil, SA514 Grade E low-alloy high-strength steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
