ASTM A514/A514M Grade J Carbon and Low-alloy High-strength Steel Coil
ASTM A514/A514M Grade J Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
| Grade | The Element Max (%) | ||||||
| C | Si | Mn | P | S | Cr | Mo | |
| A514Gr.J | 0.12-0.21 | 0.20-0.35 | 0.45-0.70 | 0.035 | 0.035 | - | 0.50-0.65 |
| Zr | B | V | Ti | Cu | Ni | ||
| - | 0.01-0.05 | - | - | - | - | ||
| Thickness (mm) | Yield strength (≥Mpa) | Tensile strength (Mpa) | Elongation in ≥,% |
| 50mm | |||
| T≤65 | 690 | 760-895 | 18 |
| 65<T | 620 | 690-895 | 16 |
ASTM A514/A514M Grade J Carbon and Low-alloy High-strength Steel Coil Application
A514/A514M Grade J carbon steel is used in Construction of Bridges, Highway Construction and Other Engineering construction.
ASTM A514/A514M Grade J Carbon and Low-alloy High-strength Steel Coil Other Name
ASTM A514/A514M Low-alloy High-strength Steel, A514/A514M Grade J carbon steel coil, A514/A514M Grade J Low-alloy High-strength Steel Coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
