ASME SA709/SA709M Grade 100W Carbon and Low-alloy High-strength Steel Coil

ASME SA709/SA709M Grade 100W Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cu
SA709 HPS 100W	≤0.08	0.95-1.50	≤0.015	≤0.006	0.15-0.50	0.90-1.20
	Ni	Cr	Mo	V	Al	N	Nb
	0.65-0.90	0.4-0.65	0.4-0.65	0.04-0.08	0.02-0.05	≤0.015	0.01-0.03

Grade	Thickness	Yield Strength	Tensile Strength	Elongation	Charpy V Impact Test
					Degree	Energy 1	Energy 2
SA709 HPS 100W	mm	Min Mpa	Mpa	Min %	-	J	J
	5＜t≤300	690	760-895	18

ASME SA709/SA709M Grade 100W Carbon and Low-alloy High-strength Steel Coil Application

SA709 Grade 100W carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.

ASME SA709/SA709M Grade 100W Carbon and Low-alloy High-strength Steel Coil Other Name

ASME SA709/SA709M low-alloy high-strength steel, SA709 Grade 100W carbon steel coil, SA709 Grade 100W low-alloy high-strength steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
